Industrial Pumps

Type 051 050 Models

051 Pumps

¼” Liquid connections Maximum 15L/min (4.0GPM)

  • 051PT

  • 051VT

  • 051AT

  • 051ST

3D viewer

050 Pumps

¼” Liquid connections Maximum 11.5L/min (3.0GPM)

  • 050PT

  • 050VT

  • 050AT

  • 050ST

3D viewer

Option

  • Optional Multiport Connections

  Type 051 Type 050
Model Name 051PT ∙ VT 051AT ∙ ST 050PT ∙ VT 050AT ∙ ST
Max Flow Rate 15 L/min 11.5 L/min
Connection Type Thread
Connection Size Air Supply ¼”
Air Exhaust – ⅜”
Liquid ¼” ※Side Port (050P Multiport)
Check Valve Type Flat
Max Solid Size 0mm
Supply Air Pressure Range 0.2 ~ 0.7MPa
Materials Wetted Body PP, CFPVDF (Glass Filled PP, CFPP) Aluminium, SUS PP, CFPVDF (Glass Filled PP, CFPP) Aluminium, SUS
Air Motor Glass Filled PP PPS
Diaphragm PTFE
